The smallest and lightest Xtar MC1 Plus Charger is capable to perform charging of cylindrical lithium-ion (Li-ion) batteries of standard sizes: 10440, 14500, 14650, 16340, 17500, 17670, 18350, 18500, 18650, 18700, 22650, 25500, 26650.
The main difference and advantage of the XTar MC1 Plus charger from the XTar MC1 is its higher charge current - the maximum charge current of the XTar MC1 Plus charger is 1000 mA (1A). This is primarily appreciated by the fans of fast charging batteries. This charger can charge a Sony VTC5 battery in just 3 hours. Like the previous model, the XTar MC1 Plus Charger has a very compact size - only 9 cm in length and about 20 grams. weight. The charger is powered via micro-USB (a power cable is supplied). As a power supply, you can use the charger from a phone, smartphone, tablet or USB output of a computer / laptop.
Charging method for Li-ion batteries: constant current charge (CC) and constant voltage charge (CV), this charging method is recommended and the fastest, conserves battery life and does not reduce their capacity over time.
Charging Current: 500mA
The final charge voltage of 4.2V
Overcharge protection (automatic shutdown of charging when the battery is fully charged).
Activation function of highly discharged batteries. Charger can recover most discharged batteries.
Soft start function prevents a sharp increase in charge current at startup, which increases the battery life cycle. The presence of a movable contact allows you to charge almost any size of Li-Ion batteries. The XTAR MC1 Charger is powered by a standard USB port on a computer, network or auto adapter.
Specifications:
- Input Voltage / Current: 5V DC / 500mA
- Charge current: 500mA
- The voltage off the charge 4.2 ± 0.05 V.
- Dimensions: 92mm x 22mm x 26mm
- Weight: 20g.
Equipment:
- Charger
- USB cable - micro USB
- Storage case
- Instruction manual
- Warranty Card
- manufacturer: XTAR;
- number of channels: 1;
- LED indication of operation: red LED - the battery is charging, green LED - the charge is over;
- 3 battery charge modes: TC-CC-CV;
- automatic detection of the full charge of batteries by voltage (4.2V);
- activation of batteries with zero charge (0V);
- protection against overheating, overcharging, incorrect polarity setting;
- legal certification in full accordance with the standards of RoHS, CE and other norms;
- input voltage: micro USB DC5V;
- charge current: 500mA / 250mA
